Are you tired of:

- Valves on the roof?
- Problems associated with direct open loop systems?
- Indirect closed loop systems that have overheating problems?
- Long, costly installations?

Then consider installing reliable, hastle-free drainback systems from Energy Labs.

With over thirty years experience as an innovative leader in the solar industry, Energy Labs is proud to introduce a revolutionary line of products that will increase your return on investment by saving time on installations.

Energy Labs' drainback tanks are aesthetically superior and competitively priced. Available with or without internal heat exchangers, these uniquely designed products are fully assembled, resulting in easy installations and time saved.

- - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - -

Drainback Tanks

Shown here is our 10 gallon drainback tank (DBT) on a Rheem HE tank.

We offer a full line of 100% stainless steel Drainback tanks in 10, 15, 20, and 30 gallon sizes.


DBT Spec Sheet (PDF 1.03MB)


DB Drainback System (PDF 143K)



DBX© Drainback Heat Exchanger Tanks:


DBX tanks go one step further with the Heat Exchanger inside the drainback tank. This allows for additional savings by purchasing only a solar storage tank or even using the existing water heater.

Offered in 10 and 15 gallon sizes, the standard DBX tanks are designed for mounting on top of the solar storage tank or water heater.

For more system customization, DBX tanks are available with different heat exchanger sizes to suit the amount of collectors used.

The 10 gallon is offered with either a 3.4ft² or a 6.2ft² surface area heat exchanger. The 15 gallon is offered with a 6.2ft² or a 9.8ft² surface area heat exchanger.


DBX Spec Sheet (PDF 1.04MB)

Side-Connect Example (PDF 355K)
Top-Connect Example (PDF 307K)

System Schematic 1 (PDF 140K)
System Schematic 2 (PDF 142K)

Retrofit Example 1 (PDF 341K)
Retrofit Example 2 (PDF 137K)
